Bison Panel Product Specifications
Bison Panel Specifications Confirming to IS 14276-2016
Bison Panel is a cement bonded particle board made out of 62% cement 28% wood. The wood used is of fast growing species like Eucalyptus and Poplar. Due to adoption of special manufacturing process, the panel acquires the strength, the durability of cement and easy workability of wood- a combination of qualities absent in other boards.
This multipurpose building board – a proven product in countries around the world is introduced in India by NCL with imported technology from Bison Werke of Germany.
| Density | 1250 Kgs/m (1100 Kgs minimum as per BIS) |
| Moisture content | 9% + 3% at Factory Point. |
| Modulus of Elasticity (bending) | 3000 N/mm2 |
| Bending strength | 9N/mm2 |
| Transverse tensile strength (perpendicular to surface) | 0.4 N/mm2 |
| Compressive strength (perpendicular to surface) | 15 N/mm2 |
| Surface Alkalinity pH | Between 11 and 13 |
| Nail holding power (perpendicular to surface) | 205 Kgs |
| Screw holding power (perpendicular to surface) | 312 Kgs |
BISON PANEL: VOLUME & WEIGHT
| Thickness | Volume per board | Weight per board | ||
| (8'x4') 2440 x 1220mm | (10'x4') 3050 x 1220mm | (8'x4') 2440 x 1220mm | (10'x4') 3050 x 1220mm |
|
| (Cu. mtrs.) | (in Kgs) | |||
| 6mm | 0.0179 | 0.0223 | 23.22 | 29.02 |
| 8mm | 0.0238 | 0.0297 | 30.95 | 38.69 |
| 10mm | 0.0297 | 0.0372 | 38.69 | 48.36 |
| 12mm | 0.0357 | 0.0446 | 46.43 | 58.03 |
| 16mm | 0.0476 | 0.0595 | 61.90 | 77.38 |
| 20mm | 0.0595 | 0.0744 | 77.38 | 96.73 |
| 30mm | 0.0892 | 0.1116 | 116.06 | 145.08 |
| 40mm | 0.1190 | 0.1488 | 154.75 | 193.44 |
TERMITE PROOF
FIRE RESISTANT
WEATHER RESISTANT
STRONG & DURABLE
SOUND INSULATION
